SZA460: Single Zone Battery Powered Portable Equipment Alarm

Flair Single Zone Gate Annunciators are attractive, low cost, battery powered alarms that can be used in a wide range of applications such as door / gate prop at hotels, pool gate security, remote yard gates / fences and anywhere you want a gate or building to be secured where there is no power. Adding a wireless transmitter will allow you to trigger an alarm at the command center, home office or lobby. Use the on board alarm relay to trigger a local camera also. The possibilities are endless.

Monitor Single Supervised 10 Foot Loop, Extensions Available
Battery Powered, 2 x AA
Audible Alarm with Timer
External Magnet Arm and Disarm
DPDT, 2 Amp, Relay
Black NEMA 4X Enclosure
Easy Magnet Mounting
Easy Fit Any Wireless Transmitter

Specifications

Part Number	SZA460
Color	Black
Input	Two Heavy Duty 10 Foot Cables to form 10 Foot Loop, Extensions Available
Mounting	Large Magnet to Clamp on Steel or Surface Mount
Power	Battery, Two AA
Size	4.75″ Tall x 4.75″ Wide x 2.50″ Deep
Ul Rating	None
Warranty	1 Year Warranty
Weight	1/2 Lb
Zones	1

Downloads

SZA460: Single Zone Battery Powered Equipment Alarm

1 file(s) 133.47 KB

Download

SZA460: Single Zone Battery Powered Equipment Alarm Instructions
