When it comes to securing heavy-duty entry points—like overhead warehouse doors, security gates, or high-traffic commercial entryways—standard residential magnetic contacts simply won’t cut it. In these environments, you deal with larger gaps, vibration, and significantly higher electrical loads. Flair Electronics has engineered three distinct series of surface mount contacts specifically designed to handle these rigors while offering the peace of mind that comes with a lifetime warranty.
Whether you need a compact solution for a standard door frame, a ruggedized aluminum housing for an industrial site, or a long-profile sensor for specialized mounting, understanding the nuances between the 1000-26S, 1000-66, and 1000-56S high-power magnetic contact series is critical for a reliable installation.
Series Breakdown: Finding Your Fit
While all three series share a common DNA of high-power capability and epoxy-sealed durability, their physical forms and lead types cater to different installation scenarios.
| Feature | 1000-26S Series | 1000-66 Series | 1000-56S Series |
| Length |
2 1/2″ |
3 1/2″ |
4″ |
| Housing Material |
Screw Mount Plastic |
Solid Aluminum Case |
Screw Mount Plastic |
| Lead Type |
12″ Center Leads |
18″ Armored Cable |
12″ Jacketed Leads |
| Available Colors |
White, Brown, Gray |
Aluminum Finish |
White, Brown, Gray |
| Configurations |
SPDT or DPDT |
SPDT |
SPDT |
Built for the Real World
Every series mentioned—whether the compact 1000-26S, the armored 1000-66, or the extended 1000-56S—is built with the same commitment to reliability.
-
Environmental Protection: Each unit is epoxy-sealed to prevent internal corrosion from moisture or industrial chemicals.
-
Security Integration: All models support internal E.O.L. resistors and supervisory loops. This ensures that if a wire is cut or tampered with, your control panel knows immediately.
-
Simplified Installation: By handling higher loads directly, these switches often eliminate the need for interposing relays, reducing your “points of failure” and simplifying your overall wiring.
Choosing a Flair high-power contact means choosing a device that won’t just “detect” a door opening, but will actively survive the electrical and physical environment it is placed in
